42 to 71" Full Motion TV Wall Mount - Dual Arm VESA 800x400
 |
Fits most: | 42" to 71" flat panels |
 |
Weight Capacity: | Supports up to 90.9kg(200lbs) |
 |
Tilt: | 5° / - 15° |
 |
Swivel: | Max 180° |
 |
Mounting profile: | 3.4" (86.9mm) Depth From Wall |
 |
Maximum extension: | 23.1" (586.9mm) |
 |
Mounts on Studs: | double-stud (mount spacing of 16") |
 |
Mounting Pattern: | Universal & VESA compliant: 200x200 to 800x400 |
 |
Roll: | 3° / - 3° |
Features
- Work with plasma, LCD and LED TVs
- Compatible with large mounting patterns, which is usually hard to find wall mount for, for example, most of Sharp 65" + LCD TVs
- Effortless adjustments for premium viewing, making it easy to reduce glare and find the perfect TV angle at any height
- Sturdy die-cast aluminum structures maximize support in a lightweight mount; rock-solid construction secures your display investment
- A mounted TV can be hung on and off the horizontal bars easily; this quick release feature is most convenient when you need to take off TV often
- Hinged arm extends TV off the wall, providing easy access to cables
- Easy accessory attachment; quick-mounting design for easy installation
- Lock-in-place feature to conclude a secure installation
- Space-saving and aesthetic design make it perfect for the home or office
- Instruction manual and mounting screws are included
Mounting Pattern
You may usually find mounting patterns dimensions on the technical drawing page of your owner's manual. Otherwise, you can simply measure from the center of one hole to the center of the next (both vertical and horizontal). Please remember to measure in millimeters. Feel free to contact us if the mounting pattern of your TV is different, and we are delighted to help you out!
Product Description
The new 42 to 71" Full Motion TV Wall Mount - Dual Arm VESA 800x400 is a full-motion mount for large size TV, with a weight capacity of 200lbs (90.9kgs), featuring 5 - 15-degree tilt, 180-degree swivel, 23.1-inch full extension & -3 to 3-degree roll. This cantilever TV wall mount is our latest breakthrough in flat panel mount design. The TV mount boasts integrated strength through the latest engineering technology and is tested for durability in our offshore manufacturing plant. The Cotytech wall mount has been built with the end-user in mind. It features easy installation while offering intuitive, practical & functional design from one of the leading manufacturers of wall mounts. If you need more information about how to select TV wall mounts, please click here. Please note that this TV wall mount is specially designed for mounting patterns up to 800x400. For TVs with mounting patterns no larger than 600x400, you may choose MW-5D1VB instead.
Comparision
Downloads
Installation Manual These downloads require Adobe Reader. To get Adobe Reader to click here.
